Toyota Corolla (E120) 2002–2008 Repair Manual / Diagnostics / ABS with EBD system / Sfr/Sfl/Srr/Srl solenoid circuit / Circuit description
Toyota Corolla (E120): Circuit description
This solenoid goes on when signals are received from the ecu and controls the pressure acting on the wheel cylinders thus controlling the braking force.
Wiring diagram
